Specification
| Model | Bearing Type |
Rated Voltage |
Operating Voltage Range |
Rated Current |
Rated Input Power |
Speed | Maximum Air Flow | Maximum Air Pressure |
Noise | Weight | ||
| PART NO. | B/S/Y | VDC | VDC | AMP | WATT | R.P.M | m3/min | CFM | mmH20 | INH2O | DB-A | 9 |
| FH2510A | B/S/Y | 5 | 3.5 to 7.0 | 0.10 | 0.50 | 5800 | 0.07 | 2.56 | 2.59 | 0.102 | 21.5 | 8.0 |
| 5 | 3.5 to 7.0 | 0.15 | 0.75 | 8500 | 0.11 | 3.46 | 3.76 | 0.148 | 26.5 | 8.0 | ||
| 5 | 3.5 to 7.0 | 0.17 | 0.85 | 10500 | 0.12 | 4.30 | 4.48 | 0.176 | 29.2 | 8.0 | ||
| 5 | 3.5 to 7.0 | 0.22 | 1.10 | 13000 | 0.16 | 5.56 | 5.89 | 0.231 | 33.5 | 8.0 | ||
| 6 | 3.5 to 9.0 | 0.33 | 1.98 | 15000 | 0.18 | 6.80 | 6.80 | 0.267 | 38.5 | 8.0 | ||
| 8.4 | 3.5 to 12.0 | 0.40 | 3.36 | 29000 | 0.35 | 12.4 | 13.13 | 0.515 | 65.2 | 8.0 | ||
| 12 | 6.0 to 13.5 | 0.03 | 0.36 | 5800 | 0.07 | 2.56 | 2.59 | 0.102 | 21.5 | 8.0 | ||
| 12 | 6.0 to 13.5 | 0.05 | 0.60 | 8500 | 0.11 | 3.46 | 3.76 | 0.148 | 26.5 | 8.0 | ||
| 12 | 6.0 to 13.5 | 0.08 | 0.96 | 10500 | 0.12 | 4.30 | 4.48 | 0.176 | 29.2 | 8.0 | ||
| 12 | 6.0 to 13.5 | 0.09 | 1.08 | 13000 | 0.16 | 5.56 | 5.89 | 0.231 | 33.5 | 8.0 | ||
| 24 | 18.0 to 27.6 | 0.02 | 0.48 | 6000 | 0.07 | 2.56 | 2.59 | 0.102 | 21.5 | 8.0 | ||
| 24 | 18.0 to 27.6 | 0.05 | 1.20 | 10000 | 0.12 | 4.30 | 4.48 | 0.176 | 29.2 | 8.0 | ||
| 24 | 18.0 to 27.6 | 0.07 | 1.68 | 12000 | 0.14 | 5.13 | 5.43 | 0.213 | 29.9 | 8.0 | ||
| 提示1：如果您需要的转速，电压，或者其它功能不在这清单上，请与我们联系，If you want another RPM,voltage or functions which one in the lise ,please contact our sales. |
||||||||||||
| 提示2:以上数据仅供参考,产品详细信息请参照承认书,如有变更恕不另行通知.Above specifcations are only for reference ,product have a detail in the approcal sheet, if specifaction are subject to change without notice. |
||||||||||||
